SUS304 Stainless Steel Facial Recognition Turnstile IP65

SUS304 Stainless Steel Facial Recognition Turnstile IP65
SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65 SUS304 Stainless Steel Facial Recognition Turnstile IP65
Grundlegende Informationen
Place of Origin: China
Markenname: DOOR or OEM
Zertifizierung: CE / IS09001
Model Number: DRTD6653
Minimum Order Quantity: 2 sets
Preis: negotiable
Packaging Details: wooden carton
Delivery Time: 5-7 working days
Payment Terms: T/T
Supply Ability: 2500 sets per month
Bestpreis Kontakt
Material: SUS304 brushed stainless steel, top cover 2.0mm, whole body 1.5mm Suitable For: Access Control, Entrance And Exit Control
Turnstile Material: SUS304 Stainless Top Cover Material: SUS304 Stainless
Communication Interface: RS485, TCP/IP interface Power Input: AC100-240V; 50/60HZ
Swing arm available: Acrylic/Stainless steel Driving Motor: Servo Motor
Working environment: -25℃-+70℃ Pass speed: 30-50p/m
Support System: Face Recognition,ic/id Card,fingerprint Motor: Servo motor
IR Sensor: 6 pairs IP Rating: IP65
Voltage: AC110V/AC220V±10% 50-60Hz Operating Power: Single Core 100w, dual core 200w
Mtbf: 5 million times Size: L1600*W160*H990mm
Method of position: Use the encoder to make sure the swing gate position
Hervorheben:

SUS304 stainless steel turnstile

,

IP65 facial recognition turnstile

,

stainless steel access control turnstile

SUS304 Stainless Steel Facial Recognition Turnstile with IP65 Rating
Product Overview

Waist Height Facial Recognition Turnstile with waterproof swing arm and brushless motor technology.

SUS304 Stainless Steel Facial Recognition Turnstile IP65 0
Technical Specifications
Attribute Value
Material SUS304 brushed stainless steel, top cover 2.0mm, whole body 1.5mm
Suitable For Access Control, Entrance And Exit Control
Communication Interface RS485, TCP/IP interface
Power Input AC100-240V; 50/60HZ
Swing arm available Acrylic/Stainless steel
Driving Motor Servo Motor
Working environment -25℃-+70℃
Pass speed 30-50p/m
Support System Face Recognition, IC/ID Card, Fingerprint
IR Sensor 6 pairs
IP Rating IP65
Voltage AC110V/AC220V±10% 50-60Hz
Operating Power Single Core 100w, dual core 200w
MTBF 5 million times
Size L1600*W160*H990mm
Method of position Use the encoder to make sure the swing gate position
Key Features
  • Modern design with fast pass speed (30-50 persons per minute)
  • Slim machine structure saves installation space
  • 6 pairs of military-grade infrared sensors with advanced algorithms for accurate detection
  • Multiple anti-clamping designs for maximum passenger safety
  • Optional widened lane for luggage and wheelchair access
  • Compatible with RS485, TCP/IP interfaces and all major access control systems
Advanced Functionality
  • Multiple passing modes: Controlled/Free/Forbidden
  • Automatic reset and self-recovery functions
  • Automatic adjustment for mechanical wear compensation
  • Built-in memory for person counting and passage tracking
  • Clear visual indicators for direction and passage status
  • Emergency fire button interfaces for automatic gate release
Integration Capabilities

Seamless third-party integration with industry-standard access control devices including IC/ID card readers, QR code scanners, and facial recognition terminals (recognition systems not included).

Customization Options
  • Minor customization
  • Drawing-based customization
  • Sample-based customization
  • Full customization available
SUS304 Stainless Steel Facial Recognition Turnstile IP65 1
Shipping fee and delivery date to be negotiated. Contact supplier for more details.
